| Part No. |
HL-MWP12X |
HL-MWP24X |
HL-MWP30X |
HL-MWP40X |
| Wattage |
12W |
24W |
30W |
40W |
| Lumen Output |
1,440 lm |
2,880 lm |
3,600 lm |
4,800 lm |
| Luminous Efficacy |
120 lm/w |
120 lm/w |
120 lm/w |
120 lm/w |
| Input Voltage |
AC100-277V |
| Dimension |
105*73*182mm ( 4.13"*2.87" *7.17" ) |
147.9*78*214.9mm (5.82"*3.07" *8.46" ) |
| Color Temp |
3000K, 4000K, 5000K, 5700K |
| CRI |
>Ra70 |
| Beam Angle |
120° |
| IP Rate |
IP65 |
| LED Driver |
Customized driver |
| Certification |
ETL / DLC |
| X' in Part No. denotes CCT and can be 'W' for 3000K, 'N' for 4000K, 'P' for 5000K, 'D' for 5700K; |
